> プロダクト > 屋外のデジタル表記 > 13.3 Inch E Ink Electronic Paper Waterproof Outdoor Android Digital Signage

13.3 Inch E Ink Electronic Paper Waterproof Outdoor Android Digital Signage

製品詳細

起源の場所: 中国

ブランド名: GENEVISION

証明: CE, FCC, ROHS, CCC

Model Number: MAD-133A-250724

支払いと送料の条件

最小注文数量: 2pc

価格: USD200-USD400/PC

パッケージの詳細: カートンおよび木箱

受渡し時間: 10 営業日

支払条件: L/C、T/T、Western Union

供給の能力: 3000セット/month

最高 の 価格 を 入手 する
製品詳細
ハイライト:
Keyword:
バス停 Eインクディスプレイ
画面サイズ:
13.3inch
決議:
1920年*1080年
明るさ:
350NITS
タッチスクリーン:
10点のPCAPのタッチ画面
カメラ:
2.0mpx 顔認識カメラ内蔵
System:
Android 7.1
AI リモコン ソフトウェア:
はい,利用可能
Keyword:
バス停 Eインクディスプレイ
画面サイズ:
13.3inch
決議:
1920年*1080年
明るさ:
350NITS
タッチスクリーン:
10点のPCAPのタッチ画面
カメラ:
2.0mpx 顔認識カメラ内蔵
System:
Android 7.1
AI リモコン ソフトウェア:
はい,利用可能
製品説明

13.3inch Retail Gender Age Recognition AI Camera Android Touch Screen Tablet Commercial Display with Passenger Flow Statistics Remote Control Software



Quick details outdoor waterproof bus station E ink display :



1. No backlight; uses reflected ambient light to display content, providing a paper-like reading experience that's easy on the eyes.

2. Fully readable even under direct sunlight, making it ideal for outdoor or brightly lit environments.

3. Consumes power only when updating the display; static images require no power, enabling long battery life.

4. Ideal for devices that display static content over long periods, such as electronic shelf labels and signage.

5. The image remains on the screen without power — known as bi-stable behavior.

6. In addition to standard black-and-white, E Ink displays are available in tri-color (black/white/red or yellow) and full-color versions for signage and advertising.

7. Near 180° viewing angle with no glare or color distortion.



Specification of electronic paper display :



Product Model Name MOG-133A-250724

Module parameters Panel Size (diagonal) 13.3 inches
  Panel Type Black and white electronic paper ink screen
  Colour Black and white, 16 grayscale
  Hink Source/Panel Manufacturer Xingtai
  Hink P/N/Panel Model ED133UT3
  Flat/ Curve/Plane/Curve Flat
  Fitting method 3mm cover glass frame sticker with AG and UV
  Front Light Support, maximum power 2.16W
Display Resolution 1600*1200
  Aspect Ratio 4:3
  Display Viewing Area(H*V) (mm)/Viewable area size 270.4(H)×202.8(V)mm
  Pixel Pitch (H)*(V) (um) Screen pixel pitch 0.169(H) ×0.169(V)mm
  Contrast Ratio (Typ.) 16:1
  View Angle(H/V) 178°(H)/178°(V)
  Panel Refresh Rate (Max.) Screen refresh rate (maximum) 75HZ
I/O HDMI-OUT 1st Road
  RJ45 1 channel 10M/100M adaptive
  USB2.0 2-way
  TF card 1 channel, maximum support 128G (optional)
  4G Optional
Android motherboard configuration (Configuration) System Android 7.1
  CPU Quad-core ARM Cortex A7 1.2G
  DDR3 1G
  EMMC 8G
  WIFI 2.4G
  BT 4.0
  Installation Support wall mounting and ceiling mounting (default wall mounting) standard VESA hole, 100*100mm, using M4 fixing screws
  KEY (4-button key) POWER, UP, DOWN, RESET
  Working indicator light (RED) The device breathes for five seconds after it is turned on, the red light will be on when charging, and the light will go out when it is turned off.
Power Power adapter Adapter with Type-c output PD protocol (optional)
  Machine power (when refreshing) ≤3.5W
  Machine power (not refreshing) ≤0.01W
  Shutdown power ≤0.001W
  Adapter powered 12V-20V/2A
  Solar powered support
software Support secondary development API and SDK available
  Refresh image time ≤2 seconds
  Brushing method Support USB flash drive
  language Support multiple languages (English by default)
Front Light Front light maximum power MAX: 2.16W
Waterproof grade Outdoor waterproof grade IP65
Machine shape and weight Overall dimensions 375*250*65mm
  Packing size /
  net weight 5.75kg
  Gross Weight About 10Kg
Packing Packing box Wooden box packaging (fumigation-free) (used abroad)
  QSG User Guide/Instructions Default electronic version
  Warranty card 1 serving
  Certificate 1 serving
Temperature and humidity Storage temperature -25℃-70℃
  Operating temperature -15℃-65℃
  humidity 10%-90%
Functional introduction of the whole machine: Wiring-free installation, energy saving and emission reduction, low-carbon eye protection. Super power saving, the product is widely used in information display screens in public areas such as outdoor smart buses, retail malls, restaurants, subways, airports, etc.



Application of waterproof IP65 E paper display:



E-readers (eBooks): This is perhaps the most well-known application, leveraging the paper-like reading experience, eye comfort, and long battery life.



Electronic Shelf Labels (ESLs): Used in retail stores to dynamically display prices and product information, allowing for instant updates from a central system with minimal power consumption.



Digital Signage (especially outdoor or low-power):

Public Information Displays: Bus stops, train stations, real-time arrival boards where sunlight readability and low power are crucial.

Outdoor Advertising/Promotional Displays: For static or infrequently updated content in bright environments.

Wayfinding Signs: In large facilities, parks, or campuses where signs need to be readable and can be solar-powered.

Menu Boards: In cafes or restaurants, offering a more natural look than backlit displays, especially for daily specials.

Gas Station Price Signs: Easy to read in all conditions and allows for quick price changes.

Smart Cards/Badges: For displaying dynamically updated information like access credentials, loyalty points, or temporary passes.

Logistics Labels/Tracking Devices: For displaying shipping information, temperature logs (cold chain monitoring), or other critical data on packages, especially where power is limited.



Industrial Applications: For displaying status updates, instructions, or sensor readings on machinery or in manufacturing facilities where robust, low-power displays are needed.



Smart Home Dashboards/Wall Displays: For displaying calendars, weather, to-do lists, or other static information without consuming much power or emitting light.



Wearable Technology (limited): While less common due to refresh rates, some wearables might use e-paper for always-on displays with long battery life.



Medical Devices: For displaying critical patient information or device status, especially in portable or low-power scenarios.



Disposable/Limited-Use Products: Where sustainability and low power consumption are paramount, such as dynamic expiry date labels on food packaging.

13.3 Inch E Ink Electronic Paper Waterproof Outdoor Android Digital Signage 0

13.3 Inch E Ink Electronic Paper Waterproof Outdoor Android Digital Signage 1

13.3 Inch E Ink Electronic Paper Waterproof Outdoor Android Digital Signage 2

13.3 Inch E Ink Electronic Paper Waterproof Outdoor Android Digital Signage 3
